Sell Double-girder Portal Crane With Hook MG manufacturer from China Henan Weihua Heavy Machinery Co., Ltd

Sell Double-girder Portal Crane With Hook

Price:	2000.0~100000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: MG

Production Capacity: according to you requiremen...

Delivery Date: 50 days or so

Power Source: Electric

Brand Name: weihua

Maximum Lifting Height: according to your requireme...

color: according to your requireme...

Means of Transport: Ocean,Land

Packing: high quality plywood crates...

Sling Type: Wire Rope

Usage: Construction Hoist

Maximum Lifting Weight: according to your requireme...

Lift Speed: according to your requireme...

Weihua Crane is the best choice!
1.No.1 Super crane manufacturer in China
2. 25 years experience
3.Demag technology
4.Absolutely reasonable price

Packaging & Delivery

Packaging Details:Delivery Detail:

Electric hoist and electricals are packaged by plastic woven cloth,main beams are packaged by plastic woven cloth for double-beam hook gantry crane.
Within 50 days after receiving your deposit

Electric hoist and electricals are packaged by plastic woven cloth,main beams are packaged by plastic woven cloth for double-beam hook gantry crane.

Within 50 days after receiving your deposit

Specifications

Double-girder crane with hook
1.Good safety protection
2.Double girder gantry crane
3.Sales first for 9 consecutive years

MG Double-girder Portal Crane with Hook

Double-girder Portal Crane with Hook: 1. A model double girder gantry crane applied outside warehouse or railway sideways to do common lifting and unloading works. 2.It is composed of bridge,support legs,crane travelling organ,winch trolley,electric equipment,strong lifting winch,the frame adopts box-type welding mechanism. 3.Operational methods:Cabin or remote control, 4.Power is supplied by cable or slide wire, 5.We offer different capacity according to your requirement,	Double-girder Crane with Hook(Trussed tyoe) 1.This kind of crane is mainly applied to port,the freight yard,windy areas and other outwork places for material handling, 2.The double girder adopts truss-type welded structure,this result to small windward side(the wind-pressure is less than 125pa) 3.Electric equipment for the trolley adopts aoft conductive cable,large carts adopts sliding contact line,and cable reel-type is available.

Double-girder Portal Crane with Hook:

1. A model double girder gantry crane applied outside warehouse or railway sideways to do common lifting and unloading works.

2.It is composed of bridge,support legs,crane travelling organ,winch trolley,electric equipment,strong lifting winch,the frame adopts box-type welding mechanism.

3.Operational methods:Cabin or remote control,

4.Power is supplied by cable or slide wire,

5.We offer different capacity according to your requirement,

Double-girder Crane with Hook(Trussed tyoe)

1.This kind of crane is mainly applied to port,the freight yard,windy areas and other outwork places for material handling,

2.The double girder adopts truss-type welded structure,this result to small windward side(the wind-pressure is less than 125pa)

3.Electric equipment for the trolley adopts aoft conductive cable,large carts adopts sliding contact line,and cable reel-type is available.

Some details of double-girder portal crane with hook:

Control method	Remote control or pendent line with press button.or closed cab is employed for operation,where there are adjustable seat,insulating mat on the floor,toughened glass for the window,fire extinguisher,electric fan and auxiliary equipment such as air conditioner,acoustic alarm and interphone which can be furnished as required by users.
Design and contruction rules	All the standards which is required for the crane is the Chinese standard
Painting color	Primer and finishing paint, Color:According to your demand, Average thickness:About 100 microns.
Power supply	380V/50HZ or as per clients' requirement
Motors	Nanjing Zongchang(Number 1 in China)
Speed	Single speed/dual speed
Manufacturing standard	All crane design and manufacturing is according to Chinese standard but customized products are available
Technical features	1.Welded construction of structural steel, 2,Lugs for securing loads, 3,Four steel wheels, 4.Capacity signs both sides, 5.Cable pendant controlled, 6.Brakes-steel wheels, 7.Steel deck
Safety features	1.Limit switch, 2.Overload stop device for hoisting, 3.Long bearing buffer for crane travelling, 4.Power failure backup,
Payment terms	40% payment in advance and the balance paid before delivery by T/T
Shipping port	Qingdao port by containers,Tianjin port by bulk cargo
Warranty	12 months
Order Notice	1.Lifting capacity?(Whether need the main hook and auxiliary hook) 2.Span length:(The center distance between the two rails) 3.Lifting height(Under hook). 4.Speed:Hoisting speed,trolley travelling speed,crane travelling speed,if our standard speed can not satisfy your working need,we can use the frequency convertor to achieve the infinite speed. 5.Working environmen,if used in the cast melting plant and explosive workshop,we will special design, 6.Workshop PDF drawing is the best choice, 7.Industrial volatges in your working areas. 8.Control mode, 9.Special demand for your actual need.
